This post should guide you through the steps on how to deploy a datapower gateway to use as a remote gateway with API Connect Reserved instance, optionally configuring the inbound management traffic through IBM Cloud Satellite Connector.

Installing the Operators

To install the operators in your cluster, the steps are as described in the documentation on how to install the operators

Set up certificates

Again follow the steps for creating certificates in the documentation.

Deploy the Gateway Cluster

Deploying the gateway cluster into Openshift is just a case of creating the GatewayCluster CR - you can start from this template.

• Create a pull-secret with access to download the datapower images and reference it under imagePullSecrets. You can download the image to mirror to your registry from the 'Download Gateway' button in the reserved instance Config Manager.

• Create a secret containing the password for the datapower admin user and ensure it is referenced under adminUser - you can use the following command to create this:

  oc create secret generic admin-secret --from-literal=password={SET-PASSWORD-HERE!}

• Update imageRegistry to point to your image registry.

• Update the jwksUrl for your reserved instance, this needs to be the platform api endpoint for the reserved instance followed by /api/cloud/oauth2/certs - you can find the platform api endpoint url from the 'Download Clients' link in the API Manager interface.

• Select and configure the appropriate profile for your cluster.

• Create a secret with the CA the reserved instance endpoints are signed by - Let's Encrypt X2 Root CA (Download from the Let's Encrypt site) and ensure the secretName for mgmtPlatformEndpointCASecret points to this.

  curl https://letsencrypt.org/certs/isrg-root-x2.pem -o isrg-root-x2.pem oc create secret generic isrg-root-x2 --from-file=ca.crt=isrg-root-x2.pem

• [Optional] If you are routing the inbound traffic through IBM Cloud Satellite Connector, you will need to configure the hostname for the gatewayManagerEndpoint to match the private cloud endpoint hostname for your connector - typically c-01.private.{region}.link.satellite.cloud.ibm.com.

• Apply the gateway cluster yaml

• You can check the status of the cluster using oc get gatewaycluster. If you see any issues you can use oc describe gatewaycluster for more details.

Set up Satellite Connector [optional]

Optionally, deploy a satellite connector agent on the same cluster as the remote gateway

• Create a Satellite Connector
• Deploy the agent
• Create a Connector Endpoint for the gateway management interface docs. For the Gateway management endpoint you will need the following details:
  • Destination FQDN: {gateway-cluster-name}-datapower.{namespace}.svc e.g. api-gateway-datapower.apicri-gateway.svc
  • Destination Port: 3000
  • TCP

Register gateway with Reserved Instance

Create TLS Client Profile so that the manager can trust the CA that signs the certificate for the gateway management endpoint. This can be done through the RI Config manager under TLS.

• Create a Trust Store containing the CA Certificate which can be obtained by copying out the ca.crt from the gateway-manager-endpoint-secret and putting it in a file named ca.pem (API Connect needs the .pem extension for the upload to be accepted.)
• Create TLS Client Profile referencing the Trust store created

Create TLS Server profiles to present to clients invoking the APIs:

• Create TLS Key Store containing the certificate and private key to present - typically these would be obtained through an external Certificate Authority.
• Create a Server profile referencing the key store created.

To register the gateway on the 'Gateways' tab you will need the following details:

• URL of management endpoint: If using Satellite, this is the link endpoint URL including the port number. If not, this will be the hostname from the gatewayManagerEndpoint in the gateway cluster CR.
• TLS Client Profile: profile created above
• Base URL of API Invocation endpoint: The host from the gatewayEndpoint in the CR that inbound clients will use
  • TLS Server Profile: profile created above

This blog post will provide you an overview of our Lambda integration in API Connect on AWS, what you could use it for and a simple worked example of setting this up. If you’d prefer you can watch me demonstrate this in our video on YouTube.

Lambda is serverless computing platform provided by Amazon Web Services (AWS) which lets you build and deploy your code in a number of different programming languages with easy integrations to AWS services without having to manage infrastructure or servers. This makes it an ideal place to build out your API implementation and when you combine this with our API Connect on AWS SaaS offering you can quickly build, manage and socialise your APIs without worrying about the infrastructure behind them.

Using our Lambda policy in the SaaS service makes this simple and straight forward to integrate these so you can build out your apis around numerous different AWS services then manage them centrally through API Connect, sharing them with consumers through our customisable developer portal.

In order to manage the integration securely we use AWS Security Token Service (STS) so there is no need for you to give API Connect the credentials for your AWS account, you can just create an IAM role and grant permission for API Connect to assume that role.

The API Connect service is running in our AWS account and we have a fixed STS role that the service uses for each region:

In your AWS account you would set up a role that has permission to invoke your Lambda function(s) and set up the principal for the trust policy to be our service role and the external ID to be your provider org ID of your API Connect service instance. You can set this role to grant permission for just a single lambda function or multiple depending on what you need.

Within API Connect you will find the Lambda policy in the API Assembly editor on the Gateway tab along with all the other policies you can use to build out your API. The preferred model is to configure the lambda policy using the STS Assume Role option, however we do also support providing an Access Key ID and Secret Access Key. Then along with the credentials you just need to specify the name of the function and the region you have the lambda function deployed in.

To do this for yourself you can follow along with my simple worked example:

1. Create Lambda function

From the AWS Console, select Lambda then Create function - either start from scratch or make use of the ‘Hello World’ blueprint example. If you start from scratch and want to use the simple echo function I demonstrate in the video, give your function a name and select NodeJS as the Runtime - you can leave all the other settings the same unless your organisation has specific requirements around roles and permissions. Then click Create function.
Here is the code for the simple example from the video, which you can copy and paste into your function - alternatively you can use an existing function or write something more useful yourself:

export const handler = async(event) => {
    // TODO implement something more interesting here!
    const response = event;
    return response;
};

After the code is updated in the function, click Deploy. Take a note of the function name and region your function is deployed in - both are part of the displayed function ARN - arn:aws:lambda:{{region}}:{{account}}:function:{{functionName}}

2. Create a role

Now you have the function created you will need to create a role to grant API Connect permission to assume which can invoke the function - for this, go to IAM and select Roles within the AWS Console.

• Select Create role
• Select Custom trust policy
• Update the trust policy to have set the Principal to the API Connect role for the region you are using (see the table above) and set the “Condition” to require an external ID of the provider org you are using in the API Connect service- you should have something like the following:

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Sid": "Statement1",
            "Effect": "Allow",
            "Principal": {
                "AWS": "arn:aws:iam::623947394061:role/ibm-apiconnect-eu-central-a"
            },
            "Action": "sts:AssumeRole",
            "Condition": {
                "StringEquals": {
                    "sts:ExternalId": "ac51909e-a379-4153-a0e8-ef4a25a83405"
                }
            }
        }
    ]
}

Next, create a permission policy for the role to allow it to invoke lambda functions - something like this (you can also specify the function within the Resource field to limit which lambda functions API Connect can invoke):

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Sid": "VisualEditor0",
            "Effect": "Allow",
            "Action": "lambda:InvokeFunction",
            "Resource": "*"
        }
    ]
}

Now you have the Lambda function and Role configured we’re ready to start making use of this function within API Connect

3. Create your API in API Connect

To do this, open API Manager - if you don't already have a trial instance to use, you can create a free trial now.

• Select Develop APIs and Products.
• Create a new API using the Add button and selecting API (from REST, GraphQL or SOAP).
• Select New OpenAPI.
• Complete the details for the name and path and click Next.
• Confirm the security options and click Next.

Now you have completed the guide to create the basic API you can set up the OpenAPI specification for it as you would like before moving on to configure the implementation. To configure the implementation, select the Gateway tab, remove the default Invoke policy by hovering over it until you see the bin icon - and then click it.

You can now drag the Lambda policy across in its place and fill in the details from your Lambda policy as the parameters (role, function name and region).

Now you have the Lambda policy in place you can Save the API, and toggle the Online indicator to make the API available to test and then try it out under the Test tab.

There we have an API implemented end to end from a serverless function in AWS Lambda through to defining the OpenAPI spec for it and managing it in API Connect. You could now go on to share this API with Consumers through the Developer Portal, or continue to build out the functionality with additional policies first.

Try it for yourself by signing up for our free 30 day trial today.

Cloud functions offer an easy way to build functionality and only pay for the time they are actually running without having to worry about how it will be hosted - you just right the code, save it and it is ready to be invoked. The function can be invoked through an event trigger or as a REST API - in this case I'm going to show how you can trigger a function as part of your API Connect assembly flow - providing an easy way to manage and socialise the functionality you have built.

To call an IBM Cloud function you first need to exchange your IBM Cloud API Key for an IAM access key using the IAM Authentication API.

This is a case of setting up and sending a post request to IBM Cloud IAM, to do this I used a set-variable policy to configure the headers and body followed by an invoke to https://iam.cloud.ibm.com/identity/token. The set-variable looks like this:

      - set-variable:
          version: 2.0.0
          title: setup iam request
          actions:
            - set: message.headers.content-type
              value: application/x-www-form-urlencoded
              type: string
            - set: message.headers.accept
              value: application/json
              type: string
            - set: message.body
              type: string
              value: >-
                grant_type=urn:ibm:params:oauth:grant-type:apikey&apikey=$(iam-apikey)​

Once you have this access key you can use this to call your function using the endpoint provided in the UI:

{

For the authentication to the function URL we need to set the Authorization header to Bearer {access_key} where access_key is from the body of the previous request, so to obtain this we can use a Parse policy to parse the returned json, and then another set-variable policy to configure the headers for the Function invoke. This time the set-variable looks like this:

      - set-variable:
          version: 2.0.0
          title: setup function call
          actions:
            - set: message.headers.authorization
              value: Bearer $(iam.body.access_token)
              type: string
            - set: message.body
              value: $(request.body)
              type: any
            - set: message.headers.accept
              value: application/json
              type: string

As you can see we're setting the authorization and accept headers, and passing the original request body from the inbound request. We follow this with an invoke of the function URL and a map, because the JSON returned from the function API includes details on invocation as well as the defined response:

{

The end to end flow looks like this:

{

Here is the complete sample swagger file which can be used in any API Connect deployment, including our new API Connect service on AWS

API Connect Reserved instance provides the ability to add remote API gateways so that you can co-locate the gateway service with your back-end systems for improved performance. With the new announcement of IBM Cloud Satellite, you can make use of this to securely expand your API Connect footprint across cloud providers and into the on-premise datacenter close to where your applications are running.

Create your Satellite location

To create a Satellite location you will need 3 hosts for the control plane, and at least one host to deploy DataPower on. For each of the hosts you will need to do the following:

• Set up the host prior based on the host requirements for Satellite.

• Register the host for RedHat updates using subscription-manager register - then apply a subscription to it in the RedHat Customer Portal

• Refresh the packages and enable the repositories

subscription-manager refresh
subscription-manager repos --enable rhel-server-rhscl-7-rpms
subscription-manager repos --enable rhel-7-server-optional-rpms
subscription-manager repos --enable rhel-7-server-rh-common-rpms
subscription-manager repos --enable rhel-7-server-supplementary-rpms
subscription-manager repos --enable rhel-7-server-extras-rpms

• Run the attach script obtained from the IBM Cloud Satellite UI to attach the host.

For the three hosts to form the control plane, you will need to assign them to the Satellite control plane through the UI or CLI.

Install DataPower in the Satellite location

• Download the DataPower rpms from your reserved instance.
• Install DataPower on your RHEL VM. In order to do this along with the pre-reqs I used the following commands:

yum install https://dl.fedoraproject.org/pub/epel/epel-release-latest-7.noarch.rpm
yum install schroot ipvsadm telnet
yum install idg_cloud1.10011.common.x86_64.rpm idg_cloud1.10011.image.x86_64.rpm

Set up link endpoint

• Create a link endpoint pointing to the API Connect Gateway management endpoint (usually port 3000)

Configure DataPower for API Connect

• Follow the steps to configure your DataPower for use with API Connect.
• For the certificates, in order to avoid a hostname mismatch create a self-signed keypair for the management interface for the hostname generated for your link endpoint.

Configure Certificate Manager service

• If you don't already have one, create a Certificate Manager instance
• Ensure API Connect Reserved Instance is authorised through IAM to access this certificate manager instance.

Add Remote gateway to your reserved instance

• Register your gateway in your API Connect Reserved Instance, filling in the details as follows:
  • Management endpoint - enter the full URL and port generated by IBM Cloud Satellite for the Link Endpoint prefixed with https://
  • Certificate - the certificate to present for the mutual TLS communication with the Gateway management
  • CA bundle - the certificate in certificate manager to use to verify the gateway management endpoint (either your CA or the certificate itself)
  • Base URL - the endpoint you want APIs to be called through - should map to the API gateway address configured in the API Connect Gateway service either directly or through a load balancer.

Currently the v10 Reserved Instance of API Connect doesn't yet have a simple approach for headless use of the CLI toolkit. The following details how to use an IBM Cloud IAM bearer token with the API Connect CLI and REST API in a headless environment such as a CI/CD pipeline.

For interactive use of the API Connect CLI, you can login using the --sso option, retreive an api key with your browser and provide that to the CLI for example:

apic-slim login --server {apic-api-endpoint} --sso

However if you want to use the CLI in a non-interactive context such as a CI/CD pipeline you need to retrieve an IBM Cloud IAM Bearer token for the toolkit to use. This can be obtained using ibmcloud iam oauth-tokens and then placed in ~/.apiconnect/token for the apic CLI to use.

The token file needs to contain:

{apic-api-endpoint}/api: |
  refresh_token: ""
  access_token: {access_token}

This can be done programmatically using something like this:

ibmcloud iam login --apikey {api-key}
ic iam oauth-tokens | sed 's/IAM token:  Bearer /api.9a6e-bd639816.us-south.apiconnect.cloud.ibm.com\/api: |\n  refresh_token: ""\n  access_token: /' > ~/.apiconnect/token

apic orgs --my --server {apic-api-endpoint}
production    [state: enabled]   https://api...apiconnect.cloud.ibm.com/api/orgs/9123ae60-427c-4997-8a6b-ddd75b169bfb
test-porg     [state: enabled]   https://api...apiconnect.cloud.ibm.com/api/orgs/b73708ea-a7b5-4d27-b562-80767e0b238e

Invoking the API Connect REST APIs

To invoke the API Connect REST APIs in Reserved Instance v10, you can use an IBM Cloud IAM token which can be obtained using the ibmcloud iam oauth-tokens CLI command or with an API call as detailed in the IAM API documentation. This token can then be used as a bearer token to invoke the API Connect REST APIs.

The full process looks like this:

Firstly use your IBM Cloud API key to retrieve an IAM token

curl -X POST \
  "https://iam.cloud.ibm.com/identity/token" \
  --header 'Content-Type: application/x-www-form-urlencoded' \
  --header 'Accept: application/json' \
  --data-urlencode "grant_type=urn:ibm:params:oauth:grant-type:apikey" \
  --data-urlencode "apikey=[your api key]"

{"access_token":"[access token would be here]","refresh_token":"not_supported","token_type":"Bearer","expires_in":3600,"expiration":1615370557,"scope":"ibm openid"}

Then take the value of the access_token and use it to call the API Connect API e.g.

curl https://{{ api_host }}/api/orgs \
  -H "Accept: application/json" \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer [access_token]

{
  "total_results": 2,
  "results": [
    {
      "type": "org",
      "org_type": "provider",
    ...
    }
  ]
}
